Ssh Configuration

For controller (raspberypi)

## ssh key generation for ssh without login
$ ssh-keygen

## copy key to workers
$ ssh-copy-id root@192.168.1.51
$ ssh-copy-id root@192.168.1.52
$ ssh-copy-id root@192.168.1.53
$ ssh-copy-id root@192.168.1.54

## pssh (parallel-ssh) install
$ sudo apt update
$ sudo apt install pssh

## make hosts.txt file
$ echo "192.168.1.51" | tee -a hosts.txt
$ echo "192.168.1.52" | tee -a hosts.txt
$ echo "192.168.1.53" | tee -a hosts.txt
$ echo "192.168.1.54" | tee -a hosts.txt

## parallel ssh to all workers
$ parallel-ssh -h hosts.txt -i -l root 'echo "hello"'

NFS Configuration

For controller (raspberypi; nfs-server)

## mount SSD
$ echo "UUID=xxxxxxxx-xxxx-xxxx-xxxxxxxxxxxx /mnt/SSD ext4 defaults,nofail 0 2" | sudo tee -a /etc/fstab
$ mount -a

## install nfs server
$ sudo apt update
$ sudo apt install nfs-kernel-server

## nfs configuration @ /etc/exports
$ echo "/mnt/SSD 192.168.1.0/24(rw,sync,no_subtree_check)" | sudo tee -a /etc/exports

## restart nfs server
$ sudo systemctl restart nfs-kernel-server

For worker (Odroid 1,2,3,4; nfs-client)

## install nfs client
$ sudo apt update
$ sudo apt install nfs-common

## mount nfs
$ sudo mkdir -p /mnt/SSD
$ echo "192.168.1.1:/mnt/SSD /mnt/SSD nfs defaults,noatime,x-systemd.automount 0 0" | sudo tee -a /etc/fstab
$ mount -a

Kubernates Configuration

k0s installation

For controller (raspberrypi)

## install k0s
$ curl -sSLf https://get.k0s.sh | sudo sh

## check dependencies
$ sudo k0s sysinfo

In case of dependency check failure, modify boot command (/boot/firmware/cmdline.txt for raspberrypi4)

console=serial0,115200 console=tty1 ... cgroup_enable=memory

## make configuration
$ sudo k0s config create | sudo tee /etc/k0s/k0s.yaml

## if needed modify the configuration

## install controller
$ sudo k0s install controller -c /etc/k0s/k0s.yaml
$ sudo k0s start

## create token for workers
$ sudo k0s token create --role=worker | sudo tee /mnt/SSD/k0s_worker_token

For worker (Odroid 1,2,3,4)

## install k0s
$ curl -sSLf https://get.k0s.sh | sudo sh

## check dependencies
$ sudo k0s sysinfo

In case of dependency check failure, modify boot command (/media/boot/boot.ini for Odroid c4)

setenv bootargs "root=UUID=... systemd.unified_cgroup_hierarchy=0"

## install worker with token
$ sudo k0s install worker --token-file /mnt/SSD/k0s_worker_token
$ sudo k0s start

## check
$ sudo systemctl status k0sworker

k0s kubernates control

## get nodes
$ sudo k0s kubectl get nodes

System Configuration

Controller : 1 x Raspberry pi 4 / Quad Cortex-A72 @ 1.8GHz / LPDDR4-3200 4GB / Debian 12 (bookworm) based Raspbian / 1GbE + USB Ethernet Adaptor / 256 GB SSD (via USB 3.0 for NFS)

Worker : 4 x Odroid c4 / Quad Cortex-A55 @ 2GHz / DDR4-2640 4GB / Ubuntu 22.04 / 1GbE

Network Configuration

dhcp server @ raspberrypi

## eth0 (for internet; Wired connection 1), eth1 (Wired connection 2) static ip setup
$ sudo nmcli connection modify "Wired connection 1" ipv4.method manual ipv4.addresses 192.168.0.100/24 ipv4.gateway 192.168.0.1 ipv4.dns 8.8.8.8
$ sudo nmcli connection down "Wired connection 1"
$ sudo nmcli connection up "Wired connection 1"
$ sudo nmcli connection modify "Wired connection 2" ipv4.method manual ipv4.addresses 192.168.1.1/24 ipv4.gateway 192.168.1.1 ipv4.dns 8.8.8.8
$ sudo nmcli connection down "Wired connection 2"
$ sudo nmcli connection up "Wired connection 2"

## dnsmasq (dhcp server) setup
$ sudo apt update
$ sudo apt install dnsmasq
$ sudo vi /etc/dnsmasq.conf

/etc/dnsmasq.conf

#interface=interface_name
interface=eth1

#dhcp-range=start_ip,end_ip,subnet_mask,lease_time
dhcp-range=192.168.1.50,192.168.1.100,255.255.255.0,12h

#dhcp-host=MAC_address,ip
dhcp-host=xx:xx:xx:xx:xx:x1,192.168.1.51
dhcp-host=xx:xx:xx:xx:xx:x2,192.168.1.52
dhcp-host=xx:xx:xx:xx:xx:x3,192.168.1.53
dhcp-host=xx:xx:xx:xx:xx:x4,192.168.1.54

#dhcp-option=3,gateway
dhcp-option=3,192.168.1.1

#dhcp-option=6,dns-server
dhcp-option=6,8.8.8.8,8.8.4.4

## restart dhcp-server
$ sudo systemctl restart dnsmasq

## NAT setup
$ sudo vi /etc/sysctl.conf

/etc/sysctl.conf

net.ipv4.ip_forward=1

## apply
$ sudo sysctl -p

## iptables NAT rule setup
## type NAT out to eth0
$ sudo iptables -t nat -A POSTROUTING -o eth0 -j MASQERADE

## save iptables
$ sudo apt install iptables-persistent
$ sudo sh -c 'iptables-save > /etc/iptables/rules.v4'

It is very easy to install chrome-driver for RaspberryPI

sudo apt-get install chromium-chromedriver

Nextcloud is very similar to Owncloud, but it has better apps.

1. Download server packages

wget https://download.nextcloud.com/server/releases/nextcloud-23.0.12.tar.bz2

※ Nextcloud 23 is the last version supporting php7.3

2. Install prerequisites

sudo apt install -y apache2 libapache2-mod-php mariadb-server openssl redis-server wget php-imagick php-common php-curl php-gd php-gmp php-bcmath php-imap php-intl php-json php-mbstring php-mysql php-ssh2 php-xml php-zip php-apcu php-redis php-ldap php-phpseclib

3. Unzip the downloaded server package

tar -jxvf nextcloud-23.0.12.tar.bz2 -C /var/www/html/
cd /var/www/html
sudo chown www-data:www-data nextcloud -R

4. Access the URL and finish to install

URL: http://<YOUR_IP>/nextcloud

Admin account

 - Username

 - Password

Storage & database

 - Data folder

 - Configure the database

    ★MySQL/MariaDB★

    Database user

    Database password

    Database name = nextcloud

    localhost

5. Modify memory cache config

When finished installation, you can check the config file( /var/www/html/nextcloud/config/config.php ).

Add the followings into CONFIG for higher performance.

'memcache.local' => '\OC\Memcache\APCu',
'memcache.locking' => '\OC\Memcache\Redis',
'redis' => [
	'host' => '/var/run/redis/redis-server.sock',
    'port' => 0,
],

1. Download server packages

wget https://download.owncloud.com/server/stable/owncloud-10.11.0.tar.bz2

2. Install prerequisites

sudo apt install -y apache2 libapache2-mod-php mariadb-server openssl redis-server wget php-imagick php-common php-curl php-gd php-gmp php-bcmath php-imap php-intl php-json php-mbstring php-mysql php-ssh2 php-xml php-zip php-apcu php-redis php-ldap php-phpseclib

3. Unzip the downloaded server package

sudo tar -jxvf owncloud-10.11.0.tar.bz2 -C /var/www/html/
cd /var/www/html
sudo chown www-data:www-data owncloud -R

4. Access the URL and finish to install

URL: http://<YOUR_IP>/owncloud

Admin account

 - Username

 - Password

Storage & database

 - Data folder

 - Configure the database

    ★MySQL/MariaDB★

    Database user

    Database password

    Database name = owncloud

    localhost

5. Modify memory cache config

When finished installation, you can check the config file( /var/www/html/owncloud/config/config.php ).

Add the followings into CONFIG for higher performance.

'memcache.local' => '\OC\Memcache\APCu',
'memcache.locking' => '\OC\Memcache\Redis',
'redis' => [
	'host' => '/var/run/redis/redis-server.sock',
    'port' => 0,
],
